Modern chemical synthesis is a pathway to many pigments some consider to be … unnatural.

At Ancient Earth Pigments we wish to minimize our use of toxic or dangerous products as much as possible; both in terms of their use, but also in terms of the environmental impact of their manufacture or extraction. This means we don’t carry many pigments of historical importance, such as the mercury-based vermilion (cinnabar), or lead white (ceruse), or the modern cadmium reds and yellows. And we also wish to avoid tremendously expensive or environmentally problematic products like Tyrian purple (from a now-rare whelk shell). However these colors played important roles in historical painting, and their absence leaves gaps in the palette that are lamentable. So we have always offered some modern synthetic pigments as substitutes for their historical predecessors.

Major changes in the use of pigments occurred throughout history, mainly in response to changes in cost or availability of certain pigments brought about by the advent of global trade. For example, the arrival of highly concentrated and inexpensive indigo from India displaced local industries in Europe and East Asia that used other plants that contained the same pigment. In Europe, of course, that blue was extracted from woad, an invasive and nutrient-intensive weed. The popularity of that blue dye had led to soil exhaustion and problems with other crops in Europe, so arrival of indigo from India displaced the local woad industry. When the Spanish brought cochineal back from the New World, it quickly displaced a similar red pigment produced by scale insects from Anatolia and Armenia. Even in the medieval era the discovery of chemical modifications, sometimes guided by the protoscience of alchemy founded in the Islamic world, led to synthesis of new pigments from completely unrelated materials. But the largest change in the use of pigments for dyes and paints in history occurred along with the Industrial Revolution, when availability of unprecedented amounts of energy and novel raw materials from fossil carbon, combined with the growing understanding of chemical principles, led to a revolution in the production of new dyes and pigments, many of which proved cheaper and more chemically suitable than their natural predecessors.

As every schoolchild knows, one signal event in the Industrial Revolution occurred in 1859 with the invention of the artificial dye mauve, by the teenage chemist William Perkin. Perkin was using the newly available product coal tar (a byproduct of coke production for making steel, or gas production from coal to light or heat cities) to try and synthesize quinine, then as now used to treat malaria. Instead, he accidentally synthesized the similar chemical structure that results, in different chemical compounds, in the blue pigments of indigo/woad or folium (discussed in earlier articles on this blog). The color he produced was the first of many aniline dyes (named for the basic chemical structure), and was exceptional in that it was colorfast and could dye silk and cotton. This resulted very quickly in wealth and fame for Perkin, who went on to be a fellow of the Royal Society and to discover many more important synthetic procedures for various pigments. Mauve itself was only briefly successful as a product, but the example of its synthesis from entirely novel components caused a tremendous stir in the newly involving industries in the Western world. Chemists, industrialists, and even politicians realized that synthesizing pigments and dyes (particularly dyes) de novo could revolutionize the industry, which was dependent on agricultural or even wild products that often came from far-off lands, often under some other country’s political or economic control (as described brilliantly in A Perfect Red, by Amy Butler Greenfield, HarperCollins, 2006). Huge industrial efforts ensued and the result today is a near infinite palette of chemicals that can be used in pigments and dyes.

The skeletal chemical structure of alizarin (Wikipedia).
Note the aromatic ring structures also found in indigo and chrozophorin (and Perkin’s original goal, quinine!).

Mauve and other aniline dyes are organic, that is to say they are compounds of organic carbon. Many currently synthesized organic dyes or pigments are duplications of compounds found in nature, but synthesized from fossil carbon. An excellent example of this is alizarin, whose synthesis process was also discovered by Perkin. Alizarin gives red color to madder, one of the classic dye plants known from ancient times, and can yield the important lake pigments rose madder and alizarin crimson. Synthesis of alizarin from coal tar (discovered by chemists at BASF in Germany in 1871) resulted in far easier and cheaper availability of alizarin dyes and pigments and madder practically disappeared as a significant crop, as did the market for cochineal bugs from South America (Greenfield, 2006). Indigo, another organic compound, is also now produced through chemical synthesis, so there’s no need to let your garden be taken over by invasive woad! Unless, of course, you want to study the historic production of blue dyes and pigments that way (which is really cool).

The Industrial Revolution also produced advances in the purification and refinement of metals, which in turn has led to the availability of modern inorganic dyes and pigments. Titanium dioxide as a pure compound was unknown to the ancients, but was first isolated from naturally occurring minerals in 1916. It is now an important white pigment with many fine art and industrial uses (and its presence in modern forgeries is often how forgers slip up!). Cadmium compounds also became available in the middle of the 19th century and have been some of the most important reds and yellows used in fine art painting because of their stability. Recently the toxicity of cadmium metal has led to increased use of azo dyes (synthetic organic compounds) in their place. However, I think it is important to acknowledge at this point that even though a particular compound we use may be safe, in most cases its precursors or its breakdown products (such as cadmium metal, or benzidine for some azo pigments) may be themselves toxic, or environmentally damaging, and don’t necessarily present a net improvement over classic pigments containing lead or mercury, like ceruse or vermilion. However, paints that are safer for the artist to use are increasingly available.

Another important category of modern synthetic pigments are the oxide pigments, produced by reacting metals with water and/or oxygen under variable conditions, or thermal decomposition of metal salts. Metal oxide pigments are the most common kind of natural earth pigment chromophores, but synthetic techniques have yielded many more kinds of coordination complexes which yield different colors and shades. Frequently the vividly colored oxide pigment is mixed with a colorless or weak colored natural earth or minerals to produce a usable pigment powder. Synthetic oxides are (mostly) as safe to use as natural earth pigments, and represent a good compromise between fidelity to historic use and cost/convenience/safety. As always, be careful and tidy when handling pigment powders, even those which are non-toxic.

Thank you for joining us as we do Pandemic Projects, meant to keep you energized, curious and learning!

Posted on Leave a comment

Ancient Earth Pigments at REALISM LIVE

Because of the pandemic, many art workshops and conferences in the US have been cancelled this year. Some in person events have been replaced with virtual conferences, which have some limitations but also provide some opportunities that are not necessarily there in person. For example, some artists may not be free to travel but can attend a conference or workshop on line! The Realism Live global virtual conference is going to be held on line (this October 20-24) in place of the FACE conference and workshop that was to be held in Baltimore this fall. Ancient Earth Pigments is a Gold sponsor of this event and is contributing gift packets for VIP ticket holders that include samples of some of our products.

We have also prepared an introductory video for the conference describing some of our products, and includes some demonstration of their use. Here is an edit of the demonstration video for your enjoyment. In addition to an introduction to some of our products, we have a demo of color preparations.

Thanks much to our videographer Charlie Kernkamp!

Posted on 1 Comment

Altered Paints – Pre-Industrial modification of natural pigments

If you’re not part of the solution, you’re part of the precipitate.

The Oldest Chemistry Joke Known To Exist

A common theme you may have noticed in the science articles on the Pandemic Blog is that a near-infinite variety of colors can be found in nature, but not all of the material that gives rise to these colors are suitable for use in painting or dyeing. However, ancient and medieval artists were not limited to the pure, stable colors found in minerals or mineral earths. Many important pigments and dyes were made throughout recorded history by taking natural products (geological or biological or both) and treating them in some way to change their color, or improve their chemical characteristics, or even to synthesize pigments from entirely different things. Many sophisticated techniques to improve the use of natural products were developed far in advance of the modern understanding of chemical principles that became codified from the 17th century on. But the ancient and medieval world nevertheless had access to many reactive chemicals, both from minerals and biological products, which could be used in making or altering pigments. Vinegar contains acid; aged urine, ammonia; Lye can be had from ash and water; salt deposits can be sources of reactive carbonates or metal salts that can be used as mordants. While ancient and medieval artisans had little notion of what we call chemistry, they were perfectly fine at experimentation and developing sophisticated techniques that had no equal until the modern era.

These rhinos from the Chauvet cave were outlined in charcoal. (Screenshot from the film “Cave of Forgotten Dreams”, Public Domain)

A witty person once said to me that the entire development of science and technology by humans can be summarized by “set fire to it (or, alternately, blow it up) and see what happens.” And indeed, among the earliest pigments used by prehistoric artists was charcoal. Charcoal can be found in the leftovers of wood fires, but from before antiquity it was intentionally made by slowly heating wood twigs to the point of combustion while restricting the access of air. In the absence of a flow of oxygen the wood does not ‘completely’ burn and oxidize to carbon dioxide (a gas of little utility if you are not a plant or a brewer), instead leaving behind a somewhat sticky, hard black residue, nearly pure carbon, that can be used to make black pigment or a very tidy, hot, and nearly smokeless fire when burned in an open fire. A very fine black pigment powder (called lampblack) can be recovered from the smoke of burning of oil in a lamp, another technique known to the ancients. You can also treat some minerals with fire or heat to alter their color. As mentioned previously, the colors burnt sienna and burnt umber are natural earth pigments treated with heat, which causes chemical reactions that reduce some of their more oxidized (and therefore brighter) iron oxides to hematite, a darker mineral. Heating white lead oxide (ceruse) can lead to a yellowish pigment that Theophilus described as a base for making flesh tones (Hawthorne and Smith, 1979). And it should be mentioned at this point that if you treat chalk or limestone with high heat, you get quicklime, a reactive chemical used to make cement or plaster and in some pigment making processes.

Another important property of pigments that artists need to take into account is solubility. Pigments that dissolve readily into water do not necessarily make good paints, as you would rely on the pigment coming out of the water solution to bind to the surface in some way. This is frequently an important part of the fabric dyeing process, where treating a dye solution with a chemical (frequently called a mordant) is required to make the dye turn the proper color and/or bind properly to the fabric. On the other hand, most paints are in fact suspensions of tiny particles of pigment in medium – they do not dissolve, but form an emulsion of sorts with the water, oil, egg yolk, etc. In many cases the same exact pigment can be used for watercolor or oil paints or tempera, because the pigment itself does not dissolve in or react with the medium.

This 14th Century (CE) Chinese dish was made from carved lacquer. That’s right: red bug excretions.
The Metropolitan Museum of Art, New York.

So some natural dyes that dissolve in water can be treated with a mordant to make them insoluble. They then precipitate out of the aqueous solution and become a solid, that can be dried and ground into a pigment powder. These pigments are called lake pigments. The term lake in this context is an English corruption (of course) of the word lac, which refers to the Indian scale insect that makes (like other highly prized bugs) a brilliant red pigment, and also a very useful waxy resin, from which we get lacquer and shellac. Lac in turn has the same root as the Sanskrit word lakh, meaning 100,000 (because there are SO. MANY. BUGS. required to make this). Presumably this also means lac pigments were used in making red lake pigments, but now, like in many bug-derived pigments, there are synthetic alternatives.

A word or two on mordants. Despite what you might think (well; I thought it), the Latin derivation of this word is not “something that makes you dead.” In fact it’s derived from mordēre, which means to “bite.” This makes great sense in the dyeing context, where mordants are used to make the water soluble dyes stay attached to the fabric. A mordant, chemically, is frequently a colorless metal salt that can form a coordination complex (as described in our earlier article) with the organic dye molecule and still have the ability to bind with something else. In the case of lake pigments it changes the dissolved pigment to an insoluble one rather than make it bind to fabric. Common mordants available from ancient times include calcium carbonate (from chalk or bone), lye (from ash), alum (from evaporated salt deposits in Egypt, or ground minerals), and green vitriol (ferrous sulfate, from certain kinds of rust).

The roots of the madder plant yield two quinine-derived dyes which can be used to make madder lake pigments and dyes.
Painting: Franz Eugen Köhler, Köhler’s Medizinal-Pflanzen (1897)

The earliest lake pigments known to be produced were indigo lakes made in ancient Egypt from the woad plant. The exact techniques the Egyptians used are not known, but it is thought that they may have used plants grown in chalky, alkaline soil (so there would be calcium carbonate or other light metal salts at hand). Perhaps the most well known lake pigment is made from madder. Madder is well known as a source of red or yellow dye from the purpurin and alizarin found in the roots. The mordants could be chalk, clay, or crushed bone (all containing calcium salts). The ancient Egyptians used gypsum (calcium sulphate hexahydrate, a brilliant white mineral found in evaporated ocean deposits) with madder to make a pink pigment.

Copper acetate was a source of blue and green color for Renaissance artists, and could be made from copper and vinegar.
(Public Domain, Photo Source)

A variety of natural pigments were made in ancient and medieval times from the oxidation products of metals. In addition to the familiar iron oxide from rust, blue pigments could be made by corroding copper in the presence of calcium carbonate (azurite is a natural mineral of this nature). Theophilus (I:34, in Hawthorne and Smith) describes a particularly nasty concoction of sulfur and mercury heated over coals produced the pigment Renaissance artists called cinnabar (after the natural mercury ore from Spain or California which can make a fine pigment itself; but the smelted metal was far more valuable and was more widely available). The pigments called “salt green” or “Spanish green” were made from copper, salt, and vinegar to produce copper acetate. Ceruse, the white pigment also used in makeup by the ancient Romans, was made from lead heated with vinegar or urine.

The blues in this 15th century manuscript were made from folium, treated with aged urine to turn the red pigment blue.
Hvalov zbornik, 1404. Illustrated Slavic manuscript from medieval Bosnia. (Public Domain image, via Wikipedia)

Finally, it was known that some pigments, in particular folium, as described in the previous article, were known to change color in response to the pH, or the acidity, of their medium. Theophilus (I:33) describes making lye and using quicklime to raise the pH of folium to change its color from red to purple to blue. Similar pH sequences are used to adjust the color of indigo as part of the mordanting process for dyeing. It was not until the 17th century that scientists realized you could turn this around and use changes in colors of certain pigments (called indicators) to determine the acidity of a solution.

To conclude, it can be safely assumed that almost any material you can think of that has color to it was subjected to some kind of attempt at alteration by ancient or medieval artisans. Heat, acid, base, and other reactive chemicals were all tried in attempts to improve natural products. In many cases successes resulted in techniques that were used for thousands of years. But many of these techniques that remained important through the Middle Ages became largely extinct, in part from the globalization of trade providing cheaper substitutes for expensive traditional materials – but in the modern era synthetic chemistry has come to dominate the production of pigments for artistic purposes. Next time we’ll talk about why and how this came to pass.

Thank you for joining us as we do Pandemic Projects, meant to keep you energized, curious and learning!


In this article we referred to the translation of “On Divers Arts” by ‘Theophilus’ (possibly Roger of Helmarshausen, ca. 1100 C.E.) by J.G. Hawthorne and C.S. Smith, Dover Publications, New York, 1979.

Posted on Leave a comment

Organic Pigments – the inside (the cell) story

Last time on the blog we discussed inorganic natural pigments: natural colors from mineral, geological sources. This time we will talk about natural organic (meaning, containing tetrahedral carbon, as opposed to inorganic carbonates or graphite or diamond) pigments, of plant and animal origin.


But first, some breaking news: An organic pigment, thought to be lost to history, has been rediscovered in its plant source, and has been for the first time chemically characterized. Portuguese scientist Paula Nabais, from the Universidade NOVA de Lisboa, and her colleagues reported last week in Science Advances (a publication of the American Association for the Advancement of Science) the results of a thorough historical and chemical investigation into folium, a stable blue pigment used in the Middle Ages for manuscript illumination, but unfamiliar and unavailable to artists in the modern era. Dr. Nabais and her colleagues read primary sources from the Middle Ages up to the 19th century CE to learn how medieval artists identified the plant (Chrozophora tinctoria) and extracted its water-soluble blue color (including some tricks and tips that may have stymied modern researchers trying to recreate the historical pigment). They then used state-of-the-art spectroscopic techniques and computer modeling to elucidate the exact chemical structure of the pigment extracted from the plants and to confirm its absorption spectrum. The pigment thus described was new to science, and was given the name chrozophoridin by Dr. Nabais and her coauthors. This is very exciting, and may lead to this ancient color returning to modern works of art.

The fruits of Chrozophora tinctoria, examples of the water-soluble folium pigment solution adsorbed into linen clothlets, and the chemical structures of hermidin (a precursor) and the newly described chrozophoridin. Figure 1 from P. Nabais, J. Oliveira, F. Pina, N. Teixeira, V. de Freitas, N. F. Brás, A. Clemente, M. Rangel, A. M. S. Silva, M. J. Melo, Science Advances 17 Apr 2020 : eaaz7772.

Organic (and organometallic) pigments differ from the inorganic pigments because of the presence of organic carbon. Carbon has several chemical forms: carbonate, graphite, diamond, and organic. Organic carbon’s particular chemical properties and reactivity have made it the basis for all biochemicals (at least on this planet). Carbon becomes organic by way of photosynthesis, in which carbon dioxide (a non-ionic inorganic form of carbon) is reduced (meaning, electrons are added), and incorporated into (at first) simple sugars, which then go on in metabolism to make carbohydrates, proteins, lipids, nucleic acids – all the useful biochemicals. Most biochemicals are, however, largely colorless, particularly in solution; think of egg whites (proteins) or sugar syrup (carbohydrates). They absorb ultraviolet light, but we can’t see this (sometimes, if the absorption spectrum is strong enough, these look somewhat yellow, as the absorption peak spills over into visible light). However, some biochemicals, including some that are in coordination with metal ions, have chemical structures that result in absorption peaks in the visible wavelength range, which means they have color. These compounds, or the portions of the compounds that are responsible for light absorption (if it’s a large compound) are frequently called chromophores.

The chemical structure of beta-carotene. Double bonds are shown as parallel lines: single bonds as single lines. Each “corner” or end of a line segment represents a carbon atom. In this kind of diagram hydrogen atoms are not shown, and you just know that there are sufficient hydrogens at each corner or end to add up to 4 bonds coming from each carbon atom. Other elements are shown by their abbreviations, but beta carotene contains nothing but carbon and hydrogen.
The alternating single and double bonds give rise to its familiar orange color.

What gives chromophores their optical properties is a particular chemical structure: alternating single and double bonds (often called conjugated bonds) between carbon atoms. This structure creates a ‘cloud’ of electrons with energy levels that can be similar to visible light photons (and thus result in absorption of the photon). The location and shape of the resulting absorption peaks depends on the number of conjugated bonds, and the shape of the structure itself. Orange and yellow carotenes, for example, are long lines of conjugated bonds, with some stuff at either end. Rings are frequently found in these structures. In The Science of Pigments we talked about the porphyrin rings that bind up metal ions to make chlorophyll or heme (found in hemoglobin or cytochromes). Open up this ring, remove the metal ion, and you get a bilin, which is a chromophore found in blue-green algae or, yes, bile. Eww.

An important chemical structure that is often part of chromophores is a ring of six carbon atoms, with alternating single and double bonds that make what is called an aromatic structure. Aromatic structures are very important biochemicals because they not only occur in strong-smelling compounds (thus the name), but they are also very chemically and physically stable. They resist chemical and physical attack quite well. Hold that thought, because one of the main factors that regulate whether a biological pigment is useful for making artistic pigment is its stability. We don’t use chlorophyll a as a painting pigment in part because if you expose it to acidic conditions or even just look at it funny the chromophore will give up its magnesium ion and turn from a lush blue-green color to a dispiriting gray in an instant. And the brilliant colors of anthocyanins of flowers (and purple carrots) can fade quickly (how disappointing it is to cook a purple carrot and see that color lost – in this case the orange or yellow carotenes are far more stable than the purple anthocyanins).

But for a moment let’s consider the role of pigments in organisms. In some cases, but not necessarily all, the color of the pigment plays some sort of crucial role in the life of the organism; sometimes the color is incidental. But, the electronic arrangements that make them able to absorb light makes them uniquely useful as biochemicals. Pigments, such as chlorophylls, absorb light energy for the purpose of photosynthesis; also, pigments can block excess light from damaging cells, like the yellow lutein or flavonoids found in land plants, or melanin in some mammals. Pigments, such as cytochromes (heme containing) are involved in electron transport chains in everything from bacteria on up, used in photosynthesis and respiration to generate chemical energy for cells. Lots of vitamins contain chromophores – and in fact the important role of translating light flux into nerve impules in the eye is played by a carotenoid derivative, retinol. Red colored heme is also found in hemoglobin, where it is used to transport oxygen through blood in many organisms. And, importantly, organisms use pigments as color for recognition purposes (colors and patterns so members of the same species can recognize each other so as to avoid mating … accidents, warning coloration for poisonous organisms), and for stealth. The bright colors of flowers, often from a diverse group of organic compounds called anthocyanins, help their pollinators recognize them (many bees can see into the ultraviolet so some flower pigments have features invisible to our eyes but stand out quite obviously to the right bee). Unfortunately, despite the wide range of colors all across the spectrum that can be produced by organic pigments, not all are suitable for making paints or dyes. The main reason for this is stability. Many of these biochemicals are evolved to be reactive: biochemical processes in the cells transform them into something else, but they can subsequently be recycled by other biochemical processes. Away from the cellular machinery that maintains them, organic pigments can break down, fall into disrepute, become fugitive.

The chemical structure of indigo. Black balls are carbon, blue are nitrogen, red are oxygen. The dotted lines indicate the aromatic structures. Via Wikipedia, by Jynto.
This file is made available under the Creative Commons CC0 1.0 Universal Public Domain Dedication.

One example of a reputable, upright, good citizen amongst organic pigments is the familiar blue of indigo. Indigo has a chemical structure that contains not one but two of those aromatic rings, in part leading to its resistance to degradation by enzymes and ultraviolet radiation. The exact role of indigo and its precursors in the cell is obscure, but it is derived from the amino acid tryptophan (which does not make you sleepy, and isn’t particularly abundant in turkey, but contains an aromatic ring, and is a component of most proteins and enzymes in all cells). Indigo is also widely distributed, occurring in multiple plant species around the world. The same pigment is found in ‘true indigo’ in the Indian subcontinent, woad in Europe, anil in America, and dyer’s knotweed in Asia. Amazingly enough the important historical color Tyrian purple contains essentially the same chemical compound as does indigo and woad, but its source is the shell of a marine snail.

Indigo requires some chemical gymnastics to properly implement as a dye or pigment (the topic of a future article?) but once extracted and properly prepared, provides a stable and beautiful color.

Yarn dyed with madder, Colonial Williamsburg (modern era). This illustrates the range of colors that can be realized from the same plant material. Photo: Madison60, licensed under the Creative Commons Attribution-Share Alike 3.0 Unported license.

Another important historical color that is known to be less of a good pigment citizen is madder. Madder is a medium sized (up to 4′) plant whose roots contain a couple different closely related anthoquinones (not terribly different from the quinine in your gin and tonic, cheers), alizarin and purpurin. These can function as antioxidants and antimicrobials in the plant, and incidentally happen to have crimson and purple colors that were much prized in the middle ages for dyeing. Madder is known to be rather fugitive as a pigment for paints (mean it breaks down over time as a result of oxidation by oxygen or sunlight), and has been largely replaced by synthetic dyes. However, madder gives us a good transition to the end of this article, as madder is one of the earliest examples of pigments that were known to have been chemically altered by people to make their properties more useful. Next time we’ll talk about ancient and modern methods of altering natural products to better suit our purposes.

Thank you for joining us as we do Pandemic Projects, meant to keep you energized, curious and learning!
